SS201 304 316L 310S Stainless Steel I Beam 321 316

MOQ:	1 MT
Price:	Negotiable
Standard Packaging:	Exporting package/wooden box package/Or per customers’ requirement
Delivery Period:	5-8 work days
Payment Method:	L/C, T/T, Western Union
Supply Capacity:	8000MT/Month

Details Information

Product Description

Detail Information

Place of Origin

Jiangsu,China

Brand Name

PU CHENG

Certification

ISO9001 14001 BV TUV PED DNV etc

Model Number

201/304/321/316/316L/310S in stock, other models can be customized

Product Name:

Stainless Steel I-Beam

Application:

Structure Building, Bridge Car Construction Etc.

Length:

6-12m, 6m 12m Or Any Length

Standard:

ASTM, ASTM SUS AISI SS

Flange Thickness:

8mm - 64mm

Web Thickness:

6.5-70mm

Flange Width:

50-400mm

Web Width:

100-630mm

Highlight:

310S Stainless Steel I Beam

316L Stainless Steel I Beam

316 stainless steel structural beams

Product Description

China Customized Stainless Steel I-Beam Sizes Hot Selling 201/ 304/ 321/ 316/ 316L/ 310S/ Customized/201/304

Descriptions

The main steel grades used to manufacture hot-rolled I-beams according to the EN 10025-2 standard are S235JR, S235J0, S235J2, S275JR, S275J0, S275J2, S355JR, S355J0 and S355J2.

I-Beam is the quintessential beam profile. The design is super strong in the vertical direction, yet has a uniform and equal response to other forces. It has the best strength to weight ratio (vertical) making it a great DIY beam profile — for Cranes, and for the main beams of big and/or long trailers.

stainless steel I beam
Length	6m or any length
Width	Size 100100mm-200200mm
Thickness	4.0mm-8.0mm
Standard	AISI,ASTM,DIN,JIS,GB ,JIS,SUS,EN,etc
Technique	Hot rolling, welding, bending
Surface Treatment	No.1/No.3/No.4/HL/1D/8K
Thickness Tolerance	±0.05mm
Material	201/304/321/316/316L/310S in stock, other models can be customized
Application	It is widely used in beam and column components of industrial and civil construction steel structure. Steel structure load-bearing support for industrial structures. Ship and machinery manufacturing frame structure. Steel piles and supporting structures of underground engineering, etc.
MOQ	1 piece
Shipment Time	200ton:Within 5days after deposit Customize Size:Within 10days after deposit OEM Product: Within 15 days after deposit
Capacity	20000 tons/month

Grade	C	Si	Mn	P	S	Ni	Cr	Mo
201	≤0.15	≤0.75	5.5-7.5	≤0.06	≤ 0.03	3.5-5.5	16.0-18.0	-
301	≤0.15	≤1.0	≤2.0	≤0.045	≤ 0.03	6.0-8.0	16.0-18.0	-
304	≤0.08	≤1.0	≤2.0	≤0.045	≤ 0.03	8.0-13.0	18.0-20.0	-
304L	≤0.03	≤1.0	≤2.0	≤0.035	≤ 0.03	9.0-13.0	18.0-20.0	-
309S	≤0.08	≤0.75	≤2.0	≤0.045	≤ 0.03	12.0-15.0	22.0-24.0	-
310S	≤0.08	≤1.0	≤2.0	≤0.045	≤ 0.03	19.0-22.0	24.0-26.0	-
314	≤0.25	≤1.5-3.0	≤2.0	≤0.045	≤ 0.03	19.0-22.0	23.0-26.0
316	≤0.08	≤1.0	≤2.0	≤0.045	≤ 0.03	10.0-14.0	16.0-18.0	2.0-3.0
316L	≤0.03	≤1.0	≤2.0	≤0.045	≤ 0.03	10.0-15.0	16.0-18.0	2.0-3.0
321	≤0.08	≤1.0	≤2.0	≤0.035	≤ 0.03	9.013	17.0-19.0	-
347	≤0.08	≤0.75	≤2.0	≤0.045	≤ 0.03	9.0-13.0	17.0-19.0
410	≤0.15	≤1.0	≤1.0	≤0.035	≤ 0.03	-	11.5-13.5	-
420	≤0.16-0.25	≤1.0	≤1.0	≤0.040	≤ 0.03	-	12.0-14.0	-
430	≤0.12	≤0.75	≤1.0	≤0.040	≤ 0.03	≤0.60	16.0-18.0	-
904L	≤0.02	≤1.0	≤2.0	≤0.045	≤ 0.03	23.0-28.0	19.0-23.0	-

Details

Product Features

Packing & Shipping

Related Products

Our Factory

Certificates

SS201 304 316L 310S Stainless Steel I Beam 321 316 7

Market

FAQ

1, What is your time of making sample ?

Usually we will take 3-5 working days to make the sample.

2, What is your MOQ ?

Usually 20 feet containers (25 tons) for section steel.

3,What is your delivery time ?

For stocks, we can send the goods to loading port within 7 working days after receiving the deposit.

For production period, it usually needs about 15days- 25 working days after receiving the deposit.

4, What is your shipping port ?

Tianjin port, Shanghai,Qingdao port, Guangzhou etc.

5, What is your payment terms ?

Usually 30% deposit by T/T in advance and balance against copy of B/L or LC at sight.
